Cyclic Allowable Stress Criteria Reciprocating Compressor 운전 시 Cylinder Nozzle로부터 전달되는 Pulsation은 배관의 진동을 발생시키고, 이에 대한 배관 시스템의 적정성 여부를 확인하기 위해 Allowable Stress를 설계시 평가해야 한다. Cyclic Allowable Stress는 Design Approach 3 절차에서 배관의 진동 기준치가 초과할 경우 최종 단계에서 평가하게 된다. Cyclic Allowable Stress Criteria는 API 618 5th에 언급되어 있으며, 370 degC 이하의 온도와 Carbon Steel 재질이 적용된 배관의 경우, Peak to Peak Cyclic Stress 기준치를 180N/mm2으로 적용한다. 또한, 배관의 Elbow, Tee, F.. 2020. 9. 2.
API 613 (5th Edition, 2007) Special Purpose Gear Units Special Purpose Gear Units for Petroleum, Chemical and Gas Industry Services 본 규격은 Special Purpose Gear Unit의 Shot Test시 적용하는 진동 기준치가 언급되어 있으며, Shaft Axial Vibration 및 Bearing Housing 또는 Shaft에서의 Radial Vibration에 대한 진동 기준치를 제시하고 있다. 1. Shaft Axial Vibration Double-Helical Gear Unit의 Shaft Axial Vibration 기준치는 Full Speed Test 또는 Slow Rotation Check의 경우로 적용한다. (1) Full Operating Speed: 50um, Peak.. 2020. 7. 14.
API 673 (3rd Edition, 2014) Centrifugal Fans for Petroleum, Chemical, and Gas Industry Services 이 규격은 Petroleum, Chemical, Gas Industry Service에 사용되는 Centrifugal Fan에 적용하며, Vendor Shop에서 Test 수행 시 적용하는 Vibration Limit을 제공하고 있다. 토출측 압력(static pressure) 상승은 Single Impeller를 기준으로 130 inch Water를 넘지 않는 Fan에 적용하며, 이 규격에서 아래 fan은 제외된다. - Axial Flow Fan - Aerial Cooler Fan - Cooling Tower Fan - Ventilation Fan - Positive Displace.. 2020. 7. 13.
API 619 (5th Edition, 2010) Rotary-type Positive Displacement Compressors for Petroleum, Petrochemical and Natural Gas Industies 본 규격은 Rotor Type Positive Displacement Compressor에 적용하며, Shop Test시 사용하는 Vibration Limit에 대해 Dry, Oil-Flooded Screw Compressor에 따라 아래와 같이 각각 명기하고 있다. 1. 진동 기준치, Dry Screw Compressor Hydrodynamic bearings Rolling element bearing Measurement on bearing housing Vibration at any speed within operatin.. 2020. 7. 10.
API 616 (5th Edition, 2011) Gas Turbines for the Petroleum, Chemical, and Gas Industry Services 본 규격은 Regenerative Cycle Combustion Gas Turbine에 적용하며, Shop Test와 Field Test에 따라 ISO 10816-4, ISO 7919-4에 준하는 Vibration Limit을 제시하고 있다. Vendor Shop Test시 진동 기준치는 Shaft 변위 또는 Bearing Housing 측정에 따라 아래와 같이 제시하고 있다. 1. Shaft 상대 변위 진동 기준치 (P-P) : ISO 7919-4의 Zone A에 준함. ○ A(P-P) : Magnitude of Unfiltered Vibration, ㎛ ○ N : Maximum C.. 2020. 6. 21.
API 617 (8th Edition, 2014) Axial and Centrifugal Compressors and Expander-compressors 본 규격은 일반 석유화학 정제용 공정에 적용되며, 아래 Compressor에 대한 진동 기준치를 제시하고 있으며, Fan 또는 Blower는 해당 규격을 적용하지 않는다. ○ Centrifugal and Axial Compressor (Part 2) ○ Integrally Geared Process Centrifugal Compressor (Part 3) ○ Expander-Compressor (Part 4) 진동 기준치는 Steam Turbine의 Shop Test시 최대 허용 운전 속도 조건에서 Shaft에 대한 P-P 변위를 측정하여 25.4um 또는 아래 운전속도에 의해 산출된 Level 중 .. 2020. 6. 20.
API 672 (4th Edition, 2004) Packaged, Integrally Geared Centrifugal Air Compressors for Petroleum, Chemical, and Gas Industry Services 본 규격은 Integrally Geared Centrifugal Air Compressor에 적용하며, 대기압으로부터 0.35bar이내로 공기를 압축하는 Equipment는 Fan 또는 Blower로 분류하며, 별도 Code를 적용한다. 진동 기준치는 Shop Test시 최대 허용 운전 속도 조건에서 Shaft에 대한 P-P변위를 측정하여 40um 또는 아래 운전속도에 의해 산출된 Level 중 낮은 값을 기준치로 적용한다. ○ A is the amplitude of unfiltered vibration, in um.. 2020. 6. 15.
API 681 (1st Edition, 2010) Liquid Ring Vacuum Pumps and Compressors for Petroleum, Chemical, and Gas Industru Services 본 규격은 Liquid Ring Vacuum Pump/Compressor에 Anti-Friction Bearing을 적용하였을 경우, Rated Speed에서 Bearing Housing의 진동 기준치를 제공하고 있으며, Vendor Shop Test뿐만 아니라 Field test에도 적용한다. Filtered Vibration 적용 시에는 Running-Speed, Vane Passing Frequency 등에서 측정된 값을 이용해야 한다. 1. 진동 기준치 ▷ (주)이너턴스 기계진동 관련 업무 소개 안정성 평가, 교차 연성계수 평가, 감쇠.. 2020. 6. 10.
API 610 (12th Edition, 2021) Centrifugal Pumps for Petroleum, Petrochemical and Natural Gas Industies 본 규격은 API 610에 따라 설계되는 Centrifugal Pump의 Vendor Shop에서 Performance Test 수행 시 측정하는 진동 값에 적용하며, 상시 운전 시 Monitoring 용도로 해당 규정치를 사용시에는 Vendor, 발주처와 별도 협의가 요구된다. 진동 측정은 Bearing Housing에서 속도를 측정하거나 베어링과 인접한 Shaft 위치에서 변위를 측정하도록 제시하고 있으며, Shut-off 운전 지점을 제외한 나머지 운전점(Allowable Operating Region)에서 진동 측정을 수행한다. 1. OH, BB 펌프의 진동 기준치 C.. 2020. 6. 9.
